February 2017

ASF130

1. Product Overview

1.1

General Description

ASF130, 3 V internally matched IF gain block amplifier MMIC, has excellent input and output return loss,

high linearity, and low noise over a wide range of frequency DC~1000 MHz, being suitable for use in

both receiver and transmitter of telecommunication systems up to 1 GHz. The amplifier is available in a

SOT363 package and passes through the stringent 100% DC & RF test via an automated test handler.

1.2

Features

 16.6 dB Gain at 150 MHz

 17.5 dBm P1dB at 150 MHz

 34 dBm Output IP3 at 150 MHz

 2.5 dB NF at 150 MHz

 MTTF > 100 Years

 Minimum External Matching Components

 Single Supply: +3 V

1.3

Applications

 Base Station Infrastructure

 Repeater

 Telecommunication System

1.4

Package Profile & RoHS Compliance

ASF130 Data Sheet

3 V IF Gain Block Amplifier MMIC over DC~1000 MHz

RoHS-compliant
