Signal

Type

Description

SPI_PIRQ Output SPI IRQ, active low, open drain, used by TPM to generate an interrupt

PP

Input

Physical Presence, active high, internal pull-down. Used to indicate Physical Presence.

GPI

Input

Used for activation and deactivation of the TPM Standby mode (

is not used, connect an external pull-up resistor (10 kΩ) to this pad.

NiC

-

Not internally connected: not connected to the die. May be left unconnected but no impact on TPM if

connected.

Note:

The VQFN32 package has a central pad (PIN33) on the bottom, which is not connected to the die. This pin does

not impact the TPM, be it connected or not.
