5.1

TSSOP28 package information

TSSOP28 is a 28-pin, 9.7 × 6.4 mm, 4.4 mm body width, 0.65 mm pitch, thin shrink small outline package.

Unless otherwise specified, general tolerance is ± 0.1 mm.

c

L

k

A1

aaa

A2

A

e

b

1

28

14

15

D

E

E1

L1

1.

Drawing is not to scale.

Symbol

millimeters

inches (1)

Min.

Typ.

Max.

Min.

Typ.

Max.

A

-

-

1.200

-

-

0.0472

A1

0.050

-

0.150

0.0020

-

0.0059

A2

0.800

1.000

1.050

0.0315

0.0394

0.0413

b

0.190

-

0.300

0.0075

-

0.0118

c

0.090

-

0.200

0.0035

-

0.0079

D

9.600

9.700

9.800

0.3780

0.3819

0.3858

E

6.200

6.400

6.600

0.2441

0.2520

0.2598

E1

4.300

4.400

4.500

0.1693

0.1732

0.1772

e

-

0.650

-

-

0.0256

-

L

0.450

0.600

0.750

0.0177

0.0236

0.0295

L1

-

1.000

-

-

0.0394

-
