ADL5206
Data Sheet
Rev. 0 | Page 18 of 25
FREQUENCY (10MHz TO 12GHz)
30
0
5
–5
2
1
–1
–2
0.5
–0.5
0.1
–0.1
GAIN = 8dB
GAIN = 14dB
GAIN = 26dB
GAIN = 32dB
M2
M3
M5
M6
Figure 54. Differential Input Reflection (SDD11) Magnitude and Phase vs.
Frequency over Four Gain
100
105
110
115
120
125
130
135
140
145
150
2
4
6
8
10 12 14 16 18
20 22 24 26 28 30 32
VOLTAGE GAIN (dB)
FREQUENCY = 100MHz
FREQUENCY = 700MHz
FREQUENCY = 1200MHz
3.3V, LOW POWER MODE
5.0V,HIGH PERFORMANCE MODE
5.0V,LOW POWER MODE
Figure 55. Spurious-Free Dynamic Range (SFDR) vs. Voltage Gain
Across Power Modes and Various Frequencies
FREQUENCY (10MHz TO 12GHz)
30
0
5
–5
2
1
–1
–2
0.5
–0.5
0.1
–0.1
GAIN = 8dB
GAIN = 14dB
GAIN = 26dB
GAIN = 32dB
M2
M3
M5
M6
Figure 56. Differential Output Reflection (SDD22) Magnitude and Phase vs.
Frequency over Four Gains
