FT81X Embedded Video Engine Datasheet

Version 1.4

Document No.: BRT_000002 Clearance No.: BRT#004

4 Function Description

The FT81x is a single chip, embedded video controller with the following function blocks:



Quad SPI Host Interface



System Clock



Graphics Engine



Parallel RGB video interface



Audio Engine



Touch-screen support and interface



Power Management

The functions for each block are briefly described in the following subsections.

4.1 Quad SPI Host Interface

The FT81x uses a quad serial parallel interface (QSPI) to communicate with host microcontrollers and

microprocessors.

4.1.1

QSPI Interface

The QSPI slave interface operates up to 30MHz. Only SPI mode 0 is supported. Refer to section 6.4.2 for

detailed timing specification. The QSPI can be configured as a SPI slave in SINGLE, DUAL or QUAD

channel modes.

By default the SPI slave operates in the SINGLE channel mode with MOSI as input from the master and

MISO as output to the master. DUAL and QUAD channel modes can be configured through the SPI slave

itself. To change the channel modes, write to register REG_SPI_WIDTH. The table below depicts the

setting.

REG_SPI_WIDTH[1:0]

Channel Mode

Data pins

Max bus speed

SINGLE – default mode

MISO, MOSI

30 MHz

DUAL

IO0, IO1

30 MHz

QUAD

IO0, IO1, IO2, IO3

25 MHz

Reserved

Table 4-1 QSPI channel selection

With DUAL/QUAD channel modes, the SPI data ports are now unidirectional. In these modes, each SPI

transaction (signified by CS_N going active low) will begin with the data ports set as inputs.

Hence, for writing to the FT81x, the protocol will operate as in FT800, with “WR-Command/Addr2, Addr1,

Addr0, DataX, DataY, DataZ …” The write operation is considered complete when CS_N goes inactive

high.

For reading from the FT81x, the protocol will still operate as in FT800, with “RD-Command/Addr2, Addr1,

Addr0, Dummy-Byte, DataX, DataY, DataZ”. However as the data ports are now unidirectional, a change

of port direction will occur before DataX is clocked out of the FT81x. Therefore it is important that the

firmware controlling the SPI master changes the SPI master data port direction to “input” after

transmitting Addr0. The FT81x will not change the port direction till it starts to clock out DataX. Hence,

the Dummy-Byte cycles will be used as a change-over period when neither the SPI master nor slave will

be driving the bus; the data paths thus must have pull-ups/pull-downs. The SPI slave from the FT81x will

reset all its data ports’ direction to input once CS_N goes inactive high (i.e. at the end of the current SPI

master transaction).

The diagram depicts the behaviour of both the SPI master and slave in the master read case.
