FT93x Datasheet Embedded Microcontroller Datasheet
Version 1.5
Document Reference No.: BRT_000051
Clearance No.: BRT#049
Pin
No.
Name
Type
Description
48
AGND
P
Analog Ground.
49
DAC_REFP
P
DAC positive reference voltage.
50
DAC1
AO
10-bit D/A converter 1, output.
51
DAC0
AO
10-bit D/A converter 0, output.
52
RTC_XIO
AO
Output from the RTC Oscillator amplifier.
53
RTC_XI/RTC_CLKIN
AI
32.768KHz clock frequency input to the RTC
Oscillator circuit or to internal RTC clock generator
circuit.
54
VDDBAT
P
+1.5V real time clock supply voltage.
55
I2CM_SCL/I2CS_SCL/
GPIO12
I/O
GPIO12 input/output. (By default is GPIO input,
internal pull-low)
I2C master serial clock input/output.
I2C slave serial clock input/output.
56
I2CM_SDA/I2CS_SDA/
GPIO13
I/O
GPIO13 input/output. (By default is GPIO input,
internal pull-low)
I2C master data line input/output.
I2C slave data line input/output.
Table 3-2 FT931 Pin Description
