Pin Descriptions Grouped by Function

Power Supply Signals

Power supply, and ground signals are described in Table 29.

Table 29 Power Supply Signals

SIGNAL NAME

PIN #

TOTAL

TYPE

SIGNAL DESCRIPTION

VDD

J13, J15, J17, J19, K12, K14, K16, K18, L11, L13, L15,

L17, L19, M12, M14, M16, M18, N13, N15, N17, N19,

P12, P14, P16, P18, R11, R13, R15, R17, R19, T12, T14,

T16, T18, U11, U13, U15, U17, U19, V12, V14, V16,

V18, W11, W13, W15, W17, W19, Y12, Y14, Y16, Y18,

AA11, AA13, AA15, AA17, AA19,

Core Supply Voltage (1.2V Input)

VDD33

B20, B28, C13, C17, C23, E15, F23, F27, H12, H14,

H16, H18, H20, J28, K20, K23, M20, N24, P20, P27,

T20, U28, V20, V23, Y20, AA6, AA24, AB3, AB10,

AB18, AB20, AB27, AE24, AF3, AF27, AH2, AH20,

AH28

I/O Supply Voltage (3.3V Input)

GND

B6, B15, B24, C3, C27, D12, D18, E2, E6, E10, E20, E24,

E28, H11, H13, H15, H17, H19, J6, J10, J12, J14, J16,

J18, J20, J24, K3, K11, K13, K15, K17, K19, K27, L10,

L12, L14, L16, L18, L20, M11, M13, M15, M17, M19,

N2, N10, N12, N14, N16, N18, N20, N28, P7, P11, P13,

P15, P17, P19, P23, R10, R12, R14, R16, R18, R20, T11,

T13, T15, T17, T19, U6, U10, U12, U14, U16, U18, U20,

U24, V3, V11, V13, V15, V17, V19, V27, W10, W12,

W14, W16, W18, W20, Y11, Y13, Y15, Y17, Y19, AA2,

AA10, AA12, AA14, AA16, AA18, AA20, AA28, AB7,

AB11, AB13, AB15, AB17, AB19, AB23, AE2, AE10,

AE20, AE28, AF7, AF12, AF18, AF23, AH6, AH15,

AH24

122

Ground

VDDF

AB12, AB14, AB16, AE6, AE15, AG13, AG17, AH10

Fabric I/O supply (3.3 or 2.5V)

VDDT

B2, B10, C7, F3, F7, H10, J2, J11, K7, K10, M10, N6,

N11, P3, P10, T10, U2, V7, V10, Y10

TLU and QMU I/O supply (3.3V)

TOTAL PINS

245
