CHAPTER 2: SIGNAL DESCRIPTIONS
C
Boundary Scan
Description Language
In order to simplify board test, Motorola Corporation has provided a boundary scan
description language (BSDL) file (c5e.bsdl) in the Motorola web site that describes the
complete set of instructions, boundary scan order, and identification code value in an
industry standard format.
http://www.motorola.com/networkprocessors
Bypass
Bypass Register
1110
Bypass
Bypass Register
1111
* There are two reserved instructions intended for Motorola Corporation’s internal
use. These should not be programmed by users.
Table 35 Instruction Register Instructions (continued)
INSTRUCTION MNEMONIC SELECTED REGISTER
INSTRUCTION OPCODE
