Data Sheet

ADA4530-1

ABSOLUTE MAXIMUM RATINGS

analog.com

Rev. C | 9 of 52

Table 4.

Parameter

Rating

Supply Voltage

17 V

Input Voltage

(V−) − 0.3 V to (V+) + 0.3 V

Input Current1

10 mA

Differential Input Voltage

±0.7 V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

Electrostatic Discharge (ESD)

Human Body Model2

4 kV

Field Induced Charged Device Model

(FICDM)3

1.25 kV

1 The input pins have clamp diodes to the power supply pins. Limit the input

current to 10 mA or less whenever input signals exceed the power supply rail

by 0.3 V.

2 Applicable Standard ESDA/JEDEC JS-001-2012.

3 Applicable Standard JESD22-C101-E (ESD FICDM standard of JEDEC).

Stresses at or above those listed under Absolute Maximum Ratings

may cause permanent damage to the product. This is a stress

rating only; functional operation of the product at these or any other

conditions above those indicated in the operational section of this

specification is not implied. Operation beyond the maximum operat-

ing conditions for extended periods may affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst case conditions, that is, a device

soldered in a circuit board for surface-mount packages using a

standard 4-layer JEDEC board.

Table 5. Thermal Resistance

Package Type

θJA

θJC

Unit

8-Lead SOIC

122

°C/W

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Charged devi-

ces and circuit boards can discharge without detection. Although

this product features patented or proprietary protection circuitry,

damage may occur on devices subjected to high energy ESD.

Therefore, proper ESD precautions should be taken to avoid

performance degradation or loss of functionality.
