Power rocker switches and indicators •

symbols and accessories

K range

U2260

45.00

(1.772)

CKRU2260-A

1

(1.441)

36.60

CKRU2280-A

1

36.60

(1.441)

CKRU2290-A

U2292

U2282

U3152

CONNECTORS

Standard color : black. Other colors : on request. Connectors cannot be combined with wiring types H and I.

U2260 6 terminal version. For use with terminals type 2, 3, 4 or 5.

6.35 (1/4) tabs to be fitted by the user (example : TE42282-2).

Can be used for the KG series.

U2282 10 terminal version. For use with terminals type H or J.

2.8 (.110) tabs to be fitted by the user (example : AMP/Tyco 0-927779-3).

U2292 10 terminal version : For use with terminals type B, C, E or F.

6.35 (1/4) tabs to be fitted by the user (example : TE42282-2).

U3152 10 terminal version. For use with terminals type B, C, E or F.

6.35 (1/4) tabs to be fitted by the user (example : "Timer" terminals TE927833-2)
