AS3701 − Detailed Description – Power Management Functions
Figure 24:
Universal IO LDO Regulator External Components
VOUT
Output voltage range
1.2
3.3
V
VLNR
Line regulation static
VIN = 2.7V to 5.5V
IOUT = 1mA
0.07
%/V
Line regulation
dynamic
VIN = 2.7V to 5.5V within 15μs
IOUT = 1mA
20
mV
VLDR
Load regulation static
IOUT = 100μA to 200mA
0.014
%/mA
Load regulation
dynamic
IOUT = 100μA to 200mA within
15
μs
30
mV
RON
ON resistance
0.5
1
Ω
IOUT
Guaranteed load
current
RMS
200
mA
ILIMIT
Short-circuit
VOUT = 0V
230
mA
IQ
Quiescent current
No Load
5
μA
IOUT = 100μA
5
IOUT = 200mA
15
IOFF
Shutdown supply
current
LDO disabled
0.1
1
μA
eN
Output noise
BW = 10Hz to 100Hz;
VOUT = 1.2V; IOUT = 1mA;
COUT = 2.2μF
112
μVrms
BW = 10Hz to 100Hz;
VOUT = 3.3V; IOUT = 1mA;
COUT = 2.2μF
205
tSTART
Startup time
750
μs
tSHUTDOWN
Shutdown time
500
μs
Symbol
Parameter
Note
Min
Typ
Max
Unit
CLDOx
Output capacitor
Ceramic X5R or X7R
2.2
4.7
μF
Symbol
Parameter
Note
Min
Typ
Max
Unit
