9

E3S-C

Note: Models numbers for Through-beam Sensors (E3S-CT61(-M1J)) are for sets that include both the Emitter and Receiver.

The model number of the Emitter is expressed by adding "-L" to the set model number (example: E3S-CT61-L 2M), the model number of the Receiver, by adding "-D"　

(example: E3S-CT61-D 2M.) Refer to Ordering Information to confirm model numbers for Emitter and Receivers.

20

57

15.8

7.4

Optical axis

Optical axis

22.2

12.9

4.2

4.2

9.2

4.2

12.9

20

25.4

31

43.8

1.5

12

32.2

2.2

7.2

Stability indicator (green)

Light indicator (red)*2

20.2

Two, M4

5.8

23

A*

1

M3

× 5

23.2

Lens (17

× 11)

M12

× 1

20.4

25.4

Two, M4

Stainless steel

(SUS304)

4-dia. vinyl-insulated round cable with 3 conductors

(Conductor cross section: 0.2 mm2 (AWG24),

Insulator diameter: 1.2 mm),

Standard length: 2 m *3

With Mounting Bracket Attached

Mounting Holes

4-dia. vinyl-insulated round cable

Standard length: 300 mm

Pre-wired Connector (-M1J)

*1. The Mounting Bracket can be attached to side A.

*2. The Emitters for Through-beam Sensors only have the power indicator (red).

*3. The Emitter cable is 4-dia.vinyl-insulated round cable with 2 conductors (conductor cross section: 0.3 mm2,

insulator diameter: 1.3 mm) and a standard length of 2 m.

Through-beam (Vertical)

E3S-CT61(-MJ)

50

Light indicator (red)

Stability indicator

(green)

22.2

9.2

4.2

6.2

38.2

8.3

29.5

17.3

25.4

20.8

2.2

4

18

9.3

1

23

9

Optical axis

Receiver

Emitter

1.5

Two, M4

Stainless steel

(SUS304)

4.2

20

M3

× 5

M12

× 1

20.4

20

18.5

A*

*The Mounting Bracket can be attached to side A.

25.4

Two, M4

Mounting Holes

Lens (17

× 11)

Pre-wired Connector (-M1J)

4-dia. vinyl-insulated round cable

Standard length: 300 mm

With Mounting Bracket Attached

4-dia. vinyl-insulated round cable with 3 conductors

(Conductor cross section: 0.2 mm2 (AWG24),

Insulator diameter: 1.2 mm),

Standard length: 2 m

Retro-/Diffuse-reflective (Horizontal)

E3S-CR11(-M1J)

E3S-CD11(-M1J)

E3S-CD12(-M1J)
