Section 7 DMA Controller (DMAC)

Rev.1.00 Jun. 07, 2006 Page 341 of 1102

REJ09B0294-0100

Table 7.3

Settings and Areas of Extended Repeat Area

SARA4 to

SARA0 or

DARA4 to

DARA0

Extended Repeat Area

00000

Not specified

00001

2 bytes specified as extended repeat area by the lower 1 bit of the address

00010

4 bytes specified as extended repeat area by the lower 2 bits of the address

00011

8 bytes specified as extended repeat area by the lower 3 bits of the address

00100

16 bytes specified as extended repeat area by the lower 4 bits of the address

00101

32 bytes specified as extended repeat area by the lower 5 bits of the address

00110

64 bytes specified as extended repeat area by the lower 6 bits of the address

00111

128 bytes specified as extended repeat area by the lower 7 bits of the address

01000

256 bytes specified as extended repeat area by the lower 8 bits of the address

01001

512 bytes specified as extended repeat area by the lower 9 bits of the address

01010

1 kbyte specified as extended repeat area by the lower 10 bits of the address

01011

2 kbytes specified as extended repeat area by the lower 11 bits of the address

01100

4 kbytes specified as extended repeat area by the lower 12 bits of the address

01101

8 kbytes specified as extended repeat area by the lower 13 bits of the address

01110

16 kbytes specified as extended repeat area by the lower 14 bits of the address

01111

32 kbytes specified as extended repeat area by the lower 15 bits of the address

10000

64 kbytes specified as extended repeat area by the lower 16 bits of the address

10001

128 kbytes specified as extended repeat area by the lower 17 bits of the address

10010

256 kbytes specified as extended repeat area by the lower 18 bits of the address

10011

512 kbytes specified as extended repeat area by the lower 19 bits of the address

10100

1 Mbyte specified as extended repeat area by the lower 20 bits of the address

10101

2 Mbytes specified as extended repeat area by the lower 21 bits of the address

10110

4 Mbytes specified as extended repeat area by the lower 22 bits of the address

10111

8 Mbytes specified as extended repeat area by the lower 23 bits of the address

11000

16 Mbytes specified as extended repeat area by the lower 24 bits of the address

11001

32 Mbytes specified as extended repeat area by the lower 25 bits of the address

11010

64 Mbytes specified as extended repeat area by the lower 26 bits of the address

11011

128 Mbytes specified as extended repeat area by the lower 27 bits of the address

111

××

Setting prohibited

[Legend]

×: Don't care
