Section 1 Overview
Rev.1.00 Jun. 07, 2006 Page 12 of 1102
REJ09B0294-0100
Classification
Abbreviation
Pin No.
(FP-144LV)
I/O
Description
Bus control
LUB
138
Output Strobe signal which indicates that the upper
byte (D15 to D8) is valid when accessing the
byte control SRAM interface space.
LLB
137
Output Strobe signal which indicates that the lower
byte (D7 to D0) is valid when accessing the
byte control SRAM interface space.
CS0
CS1
CS2-A/CS2-B
CS3-A
CS4-A/CS4-B
CS5-A/CS5-B
CS6-A/CS6-B/CS6-D
CS7-A/CS7-B
144
1
2/1
3
144/130
1/144
2/1/132
3/1
Output Select signals for areas 7 to 0.
WAIT
136
Input
Requests wait cycles when accessing the
external space.
RAS
2
Output
•
Row address strobe signal for DRAM
when area 2 is specified as DRAM
interface space.
•
Row address strobe signal when area 2 is
specified as synchronous DRAM interface
space.
CAS
3
Output Column address strobe signal when area 2 is
specified as synchronous DRAM interface
space.
WE
130
Output
•
Write enable signal for DRAM space.
•
Write enable signal when area 2 is
specified as synchronous DRAM interface
space.
OE/CKE
131
Output
•
Output enable signal for DRAM interface
space.
•
Clock enable signal for synchronous
DRAM interface space.
