656 / 1158 page  Section 11 Programmable Pulse Generator (PPG) Rev.1.00 Jun. 07, 2006 Page 604 of 1102 REJ09B0294-0100 11.5 Usage Notes 11.5.1 Module Stop State Setting PPG operation can be disabled or enabled using the module stop control register. The initial value is for PPG operation to be halted. Register access is enabled by clearing the module stop state. For details, refer to section 23, Power-Down Modes. 11.5.2 Operation of Pulse Output Pins Pins PO0 to PO15 are also used for other peripheral functions such as the TPU. When output by another peripheral function is enabled, the corresponding pins cannot be used for pulse output. Note, however, that data transfer from NDR bits to PODR bits takes place, regardless of the usage of the pins. Pin functions should be changed only under conditions in which the output trigger event will not occur. |
|
