Section 16 USB Function Module (USB)

Rev.1.00 Jun. 07, 2006 Page 796 of 1102

REJ09B0294-0100

(1) Setup Stage

USB function

Application

SETUP token reception

Receive 8-byte command

data in EP0s

To data stage

Set setup command

reception complete flag

(IFR0.SETUP TS = 1)

Automatic

processing by

this module

Clear SETUP TS flag

(IFR0.SETUP TS = 0)

Clear EP0i FIFO (FCLR.EP0iCLR = 1)

Clear EP0o FIFO (FCLR.EP0oCLR = 1)

Read 8-byte data from EP0s

Decode command data

Determine data stage direction*1

Write 1 to EP0s read complete bit

(TRG.EP0s RDFN = 1)

To control-in

data stage

To control-out

data stage

Command

to be processed by

application?

Interrupt request

Yes

Notes: 1. In the setup stage, the application analyzes command data from the host requiring processing by

the application, and determines the subsequent processing (for example, data stage direction, etc.).

2. When the transfer direction is control-out, the EP0i transfer request interrupt required in the status

stage should be enabled here. When the transfer direction is control-in, this interrupt is not required

and should be disabled.

Figure 16.10 Setup Stage Operation
