COMSET SEMICONDUCTORS

3/3

NPN 2N5671 – 2N5672

MECHANICAL DATA CASE TO-3

DIMENSIONS

mm

inches

A

25,51

1,004

B

38,93

1,53

C

30,12

1,18

D

17,25

0,68

E

10,89

0,43

G

11,62

0,46

H

8,54

0,34

L

1,55

0,6

M

19,47

0,77

N

1

0,04

P

4,06

0,16

Pin 1 :

Base

Pin 2 :

Emitter

Case :

Collector
