timer pin timing

Valid logic-level periods and polarity are specified by the contents of the internal control registers.

The following tables define the timing parameters for the timer pin. The numbers shown in Figure 31 correspond with those in the NO. column

of the tables below.

NO.

DESCRIPTION‡

’LC31-33

’C31-40,

’LC31-40

UNIT

MIN

MAX

MIN

MAX

88

tsu(TCLK-H1L) Setup time, TCLK external before H1 low

12

10

ns

89

th(H1L-TCLK)

Hold time, TCLK external after H1 low

0

0

ns

90

td(H1H-TCLK)

Delay time, H1 high to TCLK internal valid

10

9

ns

91

t (TCLK)

Cycle time TCLK

TCLK ext

tc(H)×2.6

tc(H)×2.6

ns

91

tc(TCLK)

Cycle time, TCLK

TCLK int

tc(H)×2

tc(H)×2

ns

92

t (TCLK)

Pulse duration TCLK high/low

TCLK ext

tc(H)+12

tc(H)+10

ns

92

tw(TCLK)

Pulse duration, TCLK high/low

TCLK int

[tc(TCLK)/2]–15

[tc(TCLK)/2]+5

[tc(TCLK)/2]–5

[tc(TCLK)/2]+5

ns

† Timing parameters 88 and 89 are applicable for a synchronous input clock. Timing parameters 91 and 92 are applicable for an asynchronous input clock.

‡ Specified by design but not tested

NO

DESCRIPTION‡

’C31-50

’C31-60

’C31-80

UNIT

NO.

DESCRIPTION‡

MIN

MAX

MIN

MAX

MIN

MAX

UNIT

88

tsu(TCLK-H1L)

Setup time, TCLK external

before H1 low

8

6

5

ns

89

th(H1L-TCLK)

Hold time, TCLK external

after H1 low

0

0

0

ns

90

td(H1H-TCLK)

Delay time, H1 high to TCLK

internal valid

9

8

6

ns

91

t (TCLK)

TCLK ext

tc(H)×2.6

tc(H)×2.6

tc(H)×2.6

ns

91

tc(TCLK)

TCLK int

tc(H)×2

tc(H)×2

tc(H)×2

ns

92

t (TCLK)

TCLK ext

tc(H)+10

tc(H)+10

tc(H)+6

ns

92

tw(TCLK)

TCLK int

[tc(TCLK)/2]–5

[tc(TCLK)/2]+5

[tc(TCLK)/2]–5

[tc(TCLK)/2]+5

[tc(TCLK)/2]–5

[tc(TCLK)/2]+5

ns

† Timing parameters 88 and 89 are applicable for a synchronous input clock. Timing parameters 91 and 92 are applicable for an asynchronous input clock.

‡ Specified by design but not tested
