PACDN042

www.onsemi.com

3

Table 1. PIN DESCRIPTIONS

Pins

Name

Description

(Refer to Package Outline Drawings)

TVS Cathode

The cathode of the respective TVS diode, which should be connected to the

node requiring transient voltage protection.

(Refer to Package Outline Drawings)

GND

The anode of the TVS diodes.

SPECIFICATIONS

Table 2. ABSOLUTE MAXIMUM RATINGS

Parameter

Rating

Units

Storage Temperature Range

−65 to +150

°C

Package Power Dissipation

SC70

SOT23−3, SOT23−5, SOT23−6, SOT−143

TSSOP, MSOP

0.2

0.225

0.5

W

Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality

should not be assumed, damage may occur and reliability may be affected.

Table 3. STANDARD OPERATING CONDITIONS

Parameter

Rating

Units

Operating Temperature

−40 to +85

°C

Table 4. ELECTRICAL OPERATING CHARACTERISTICS

Symbol

Parameter

Conditions

Min

Typ

Max

Units

C

Capacitance

30

pF

Reverse Stand−off Voltage

5.5

V

6.1

V

Leakage Current

1

100

nA

Small Signal Clamp Voltage

Positive Clamp

Negative Clamp

6.2

−0.4

6.8

−0.8

8

−1.2

V

ESD Withstand Voltage

Human Body Model, MIL−STD−883,

Method 3015

Contact Discharge per IEC 61000−4−2

Standard

(Note 1)

(Note 1)

±30

±20

kV

Diode Dynamic Resistance

Forward Conduction

Reverse Conduction

1.0

1.4

W

Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product

performance may not be indicated by the Electrical Characteristics if operated under different conditions.

1. ESD voltage applied between channel pins & ground, one pin at a time; all other channel pins open; all GND pins grounded.
