Unit：mm

http://www.ddknet.co.jp

CM02 Series

5

◎ Specifications and/or dimensions in this catalog are subject to change without notice.

　 Your checking the latest specifications with our drawings would be highly appreciated.

○“Ｔ ”Tap

○Terminating Resistor With Pin Contacts

○Terminating Resistor With Socket Contacts

○Receptacle with Metal Shell and Pin Contacts, Type 1

P/N : CM02-8D2TA5-CF

Plug

（Socket）

Plug

（Socket）

Jack

（Pin）

ＪＡＰＡＮ

10.2

23.6

17

φ4.5

15

18.4

2.5

2.5

φ7.8

P/N : CM02B-8DER5P

1

2

3

4

5

NC

NC

NC

121Ω

M12×1 Thread

43

P/N：CM02B-8DER5S

1

2

3

4

5

NC

NC

NC

121Ω

40

M12×1 Thread

P/N : CM02-8DR5P-CF

17

１

２

３

４

φ14

+0.1

0

Mounting Hole

M12×1 Thread

３ Max.

(Panel Thickness)

23

M14×0.75 Thread

○Receptacle with Metal Shell and Pin Contacts, Type 2

P/N : CM02-8DR5P-CF(D5)

Mounting Hole

１

２

３

４

M121 Thread

φ14

+0.1

0

３ Max.

19.4

φ1

9.6

(2.7)

17

(Panel Thickness)

M140.75 Thread

Wiring Diagram

Wiring Diagram

・Rear-mount configuration

・Applicable wire size : AWG22 max.

・Rear-mount configuration

・Applicable wire size : AWG22 max.

・Terminated between No. 4 and No. 5 with resistor,　121 ohm,1/4 watt.

・Terminated between No. 4 and No. 5 with resistor,　121 ohm,1/4 watt.
