Unit：mm

http://www.ddknet.co.jp

CM02 Series

6

◎ Specifications and/or dimensions in this catalog are subject to change without notice.

　 Your checking the latest specifications with our drawings would be highly appreciated.

○Plug Insert Assembly with Socket Contacts for PCB Mount

○ Receptacle with Plastic Shell and Pin Contacts

○Plug Receptacle with Metal Shell and Socket Contacts

○Receptacle Cap

○Plug Cap

P/N : CM02-8DR5PD(D1)-FG

Panel Mounting Hole

3 Max.（Panel Thickness）

M12×1 Thread

M14×0.75 Thread

0

17

3.5

5.9

1

Board Thickness

23.4

19.6

1.5

6

Board Mounting Hole

2.5

2.5

5-φ１

45°

φ15

No Printed Area

Coding Pin

φ1.4

9

P/N : CM02-8DPR5S-CF

Mounting Hole

1

2

3

4

１

４

３

２

M12×1 Thread

M16×1 Thread

15.8

19

0

P/N : CM02-8DP5SD(D1)-FG

Board Mounting Hole

2.5

2.5

5-φ１

10

15

3.5

Coding Pin

φ1.4

45°

3.2

45°

13

8.7

14.3

φ3.2

18

13

straight knurl

100

Metal Cap for Plug

Metal Cap for Receptacle

Waterproof type

Material/Finish : Copper Alloy/Nickel Plating

Waterproof type

Material/Finish：Aluminum Alloy/Anodic Coatings

P/N : CM01-P-CAP-CF

Waterproof type

Material/Finish : Copper Alloy/Nickel Plating

P/N：CM01-CAP

P/N : CM01-R-CAP-CF

P/N：CM01-R-CAP(D1)

・P C B Contacts

・No shell

Please varify that above P/N is NOT waterproof type.

・Rear-mount configuration

・Applicable wire size : AWG22 max.

・P C B Contacts

・Rear-mount configuration

Non-Waterproof type

Material : PVC/Black
