SSM3515CCBZ-R7 datasheet(8/41 Pages) AD

8 / 41 page

SSM3515

Data Sheet

Rev. A| Page 8 of 41

ABSOLUTE MAXIMUM RATINGS

Absolute maximum ratings apply at TA = 25°C, unless otherwise

noted.

Table 7.

Parameter

Rating

PVDD Supply Voltage

−0.3 V to +18 V

VREG18/DVDD Supply Voltage

−0.3 V to +1.98 V

VREG50/AVDD Supply Voltage

−0.3 V to +5.5 V

PGND and AGND Differential

±0.3 V

ADDR, SDATA Input Voltage

−0.3 V to +1.98 V

SCL, SDA, BCLK, FSYNC Input Voltage

−0.3 V to +5.5 V

REG_EN Input Voltage

−0.3 V to +18 V

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +165°C

Lead Temperature Range

(Soldering, 60 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA (junction to air) is specified for worst case conditions, that is,

a device soldered in a circuit board for surface-mount packages. θJA

and θJB are determined according to JESD51-9 on a 4-layer

printed circuit board (PCB) with natural convection cooling.

Table 8. Thermal Resistance

Package Type

θJA

Unit

20-Ball, 1.8 mm × 2.2 mm WLCSP

55.5

°C/W

ESD CAUTION
