20 / 41 page ![]() SSM3515 Data Sheet Rev. A| Page 20 of 41 ADDR PIN SETUP AND CONTROL The ADDR pin sets the device I2C address. See Table11 for details. CLOCKING In 3-wire mode (BCLK, FSYNC, SDATA), a BCLK signal must be provided to the SSM3515 for correct operation. The BCLK signal must have a minimum frequencyof 2.048 MHz.The BCLK signal is used for internal clocking of the device. The BCLK rate is detected automatically, but the sampling frequency must be known to the device. The supported BCLK rates at 32 kHz to 48 kHz are 50, 64, 100, 128, 192, 200, 256, 384, 400, and 512 times the sample rate. Table 11. Pin Setup List ADDR Pin SCL Pin SDA Pin Control Mode 7-Bit I2C Address TDM Slot Connected to Ground Using a 47 kΩ Resistor SCL SDA I2C 0x14 1 Open (No Connection) SCL SDA I2C 0x15 2 Connected to 1.8 V Using a 47 kΩ Resistor SCL SDA I2C 0x16 3 Connected to 1.8 V SCL SDA I2C 0x17 4 |
|
