Data Sheet

ADA4510-2

SPECIFICATIONS

analog.com

Rev. B | 7 of 32

Table 2. Electrical Specifications for TA = −40°C to +125°C (Continued)

Parameter

Test Conditions/Comments

Min

Typ

Max

Unit

Open-Loop Voltage Gain (AVOL)

RL = 10 kΩ, −19.7 V < VOUT < 19.7 V, TA = 25°C

126

140

−40°C < TA < +125°C

112

RL = 2 kΩ, −19.1 V < VOUT < 19.1 V, TA = 25°C

121

134

−40°C < TA < +125°C

106

Input Capacitance

Differential Mode (CINDM)

TA = 25°C

Common Mode (CINCM)

TA = 25°C, VSY = ±5 V to ±20 V

Input Resistance

Differential Mode (RINDM)

TA = 25°C

TΩ

Common Mode (RINCM)

TA = 25°C

TΩ

NOISE PERFORMANCE

Voltage Noise (en p-p)

0.1 Hz to 10 Hz, TA = 25°C

µV p-p

0.1 Hz to 10 Hz, VCM = (V+) − 1.5 V, TA = 25°C

2.7

µV p-p

Voltage Noise Density (en)

f = 100 Hz, TA = 25°C

nV/√Hz

f = 1 kHz, TA = 25°C

nV/√Hz

f = 100 Hz, VCM = (V+) − 1.5 V, TA = 25°C

nV/√Hz

f = 1 kHz, VCM = (V+) − 1.5 V, TA = 25°C

nV/√Hz

Current Noise Density (In)

f = 10 Hz, TA = 25°C

fA/√Hz

OUTPUT CHARACTERISTICS

Output Swing High (VOH)

((V+) − VOUT)

RL = 10 kΩ, TA = 25°C

100

116

−40°C < TA < +125°C

187

RL = 2 kΩ, TA = 25°C

430

473

−40°C < TA < +125°C

765

Output Swing Low (VOL)

(VOUT − (V−))

RL = 10 kΩ, TA = 25°C

−40°C < TA < +125°C

142

RL = 2 kΩ, TA = 25°C

310

342

−40°C < TA < +125°C

573

Output Current (IOUT)

(VOH, VOL) < 1 V, TA = 25°C

±22

Short-Circuit Current (ISC)

Sourcing/sinking, TA = 25°C

55/70

Closed-Loop Output Impedance (ZOUT) f = 1 kHz , TA = 25°C

Gain = 1

mΩ

Gain = 10

190

mΩ

Gain = 100

1.9

Open-Loop Output Impedance (ZO)

f = 1 kHz to 1 MHz, TA = 25°C

190

POWER SUPPLY

VSY ((V+) − (V−))

Guaranteed by PSRR

Power Supply Rejection Ratio (PSRR)

VSY = ±3 V to ±20 V, TA = 25°C

121

140

−40°C < TA < +125°C

116

Supply Current per Amplifier (ISY)

IOUT = 0 mA, TA = 25°C

1.45

1.55

−40°C < TA < +125°C

DYNAMIC PERFORMANCE

Slew Rate

VOUT = ±5 V, gain = 1, 10% to 90%, TA = 25°C

V/µs

Gain Bandwidth Product (GBP)

f = 100 kHz, TA = 25°C

10.4

MHz

−3 dB Bandwidth

Gain = 1, TA = 25°C

13.5

MHz
