Data Sheet

ADA4511-2

SPECIFICATIONS

analog.com

Rev. A | 5 of 28

Table 1. Electrical Specifications (Continued)

Parameter

Test Conditions/Comments

Min

Typ

Max

Unit

Closed-Loop Output Impedance (ZOUT) f = 1 kHz

Gain = 1

mΩ

Gain = 10

190

mΩ

Gain = 100

1.9

Open-Loop Output Impedance (ZO)

f = 1 kHz to 1 MHz

190

POWER SUPPLY

(V+) − (V−) (VSY)

Guaranteed by PSRR

Power-Supply Rejection Ratio (PSRR)

VSY = ±3 V to ±20 V

121

140

−40°C < TA < +125°C

116

Supply Current per Amplifier (ISY)

IOUT = 0 mA

1.45

1.55

−40°C < TA < +125°C

DYNAMIC PERFORMANCE

Slew Rate

VOUT = ±5 V, Gain = 1, 10% to 90%

V/µs

Gain Bandwidth Product (GBP)

f = 100 kHz

10.4

MHz

−3 dB Bandwidth

Gain = 1

13.5

MHz

Settling Time (tS)

To 0.01%

Gain = −1, VOUT = 5 V step

1.9

µs

Gain = −1, VOUT = 10 V step

2.2

µs

To 0.001%

Gain = −1, VOUT = 5 V step

3.1

µs

Gain = −1, VOUT = 10 V step

3.5

µs

Output Overload Recovery Time

Gain = −10, positive/negative

300/100

Total Harmonic Distortion (THD)

VOUT = 10 V p-p, Gain = 1

f = 1 kHz

0.00002

f = 1 kHz

−134

f = 50 kHz

0.00446

f = 50 kHz

−87

ELECTROMAGNETIC INTERFERENCE

REJECTION RATIO (EMIRR)

EMIRR = 20 × log10(∆VIN/∆VOS), ∆VIN = 200 mV p-p

f = 1000 MHz

f = 2400 MHz
