TYPICAL PERFORMANCE CHARACTERISTICS

analog.com

Rev. A | 8 of 28

V+ = +20 V, V− = −20 V, VCM = 0 V, RL = 10 kΩ to midsupply, TA = 25°C, unless otherwise noted.

Figure 3. VOS Distribution at 25°C

Figure 4. VOS Distribution at −40°C, SOIC_N

Figure 5. VOS Distribution at 125°C, SOIC_N

Figure 6. TCVOS Distribution from −40°C to +125°C

OFFSET VOLTAGE (µV)

–80 –65 –50 –35 –20 –5

10

25

40

55

70

85

100

0

5

10

15

20

25

30

35

40

240 AMPLIFIERS

MSOP

MEAN = 24.5µV

SD = 25.3µV

Figure 7. VOS Distribution at −40°C, MSOP

240 AMPLIFIERS

MSOP

MEAN = 5µV

SD = 29µV

OFFSET VOLTAGE (µV)

–120 –100 –80 –60 –40 –20

0

20

40

60

80

100

0

5

10

15

20

25

30

35

Figure 8. VOS Distribution at 125°C, MSOP
