7 / 38 page

E3X-NH

Attachments

Name

Long Distance Lens Unit

Applications

Increasing sensing distance

Model

E39-F1

Appearance

Through-beam

(separate)

Applicable fibers

E32-T11L

E32-TC200

E32-T61

E32-T11R

E32-T11

With

E3X NH11/41

Sensing distance

2,000 mm

3,000 mm

2,100 mm

2,000 mm

E3X-NH11/41

Standard object

Opaque objects: 4-mm dia. min.

Directivity

° to 40°

Differential travel

---

Ambient temperature

E32-T61: –40

°C to 200°C (Do not exceed the operating temperature of the fiber. )

Material

Shaft

Brass

ae a

Lens

Optical glass

Base

---

Reflector

---

Name

Side-view Unit

Applications

Changing the sensing direction at

°90

Model

E39-F2

Appearance

Through-beam

(separate)

Applicable fibers

E32-T11L

E32-TC200

E32-T11R

E32-T61/11

With

E3X NH11/41

Sensing distance

400 mm

500 mm

350 mm

400 mm

E3X-NH11/41

Standard object

Opaque objects: 3-mm dia. min.

Directivity

° to 60°

Differential travel

---

Ambient temperature

E32-T61: –40

°C to 200°C (Do not exceed the operating temperature of the fiber.)

Material

Shaft

Brass

ae a

Lens

Optical glass

Base

---

Reflector

---
