E39-R1 datasheet(30/38 Pages) OMRON

30 / 38 page

E3X-NH

E32-R21

(One E39-R3 Re-

flector is supplied

with the Sensor.)

E32-D73

Note:

Section A resists 400

°C, section B resists 300°C, and section C (which is inserted to the Amplifier)

resists 110

°C. The operating temperature of the section to be inserted (marked with *) must be within

the operating temperature range of the Amplifier.

1.0 dia.

SUS303

Two hexagon clamping nuts

Two toothed washers

Sensing head

1.25 dia.

SUS flexible tube

Hexagon

clamping

screw

Sleeve

1.65 dia. 2.5 dia.

4 dia.

2.8 dia.

5 dia.

M4 x 0.7 (SUS303)

(see note)

Lens

(PMMA)

Silicone tube

Optical fibers,

two, 1 dia.

Two fiber attachments (E39-F9)

Sensing

head

(ABS)

Two hexagon clamping nuts

Two washers

M6 x 0.75

5 dia.

E32-R16

(One E39-R1

Reflector is

supplied with

the Sensor.)

Lens (PMMA)

Mounting bracket (attachment)

Two, M3 screws (attachment)

Optical fiber, two, 2.2 dia.

Standard length: 2 m

Sensing head (ABS)

E32-L25

E32-L25A

Note:

The fiber for the emitter is

identified by a white line.

Optical fiber, two, 2.2 dia.

Two, 3.2 dia.,

6 dia. spot facing

Two, 3.2 dia.,

6 dia. spot facing

Optical fiber,

two, 2.2 dia.

Sensing head (heat resistive ABS)

Sensing head

(heat resistive

ABS)

Sensing distance
