Phihong USA Corporation • 47800 Fremont Blvd. Fremont, CA 94538 • Tel: 1.510.445.0100 Fax: 1.510.445.1678

www.phihong.com or www.midspans.com

-17-

2.6

Technical Speciﬁcations

Model Name:

POE

U-

-N-R

RoHS

NIC Interface

Power over Ethernet

2-3 digits specifying the

total power rating

2 letters specifying the

power level per port

1-2 digits specifying the

total number of output

ports

General Eletrical Speciﬁcations:

•

Input

AC Input Voltage Rating

100VAC to 240VAC

AC Input Voltage range

90VAC to 264VAC

AC Input Current

Varies per model

AC Input frequency

47Hz to 63Hz

Max. In-rush current

30A for 115VAC at Max. load

60A for 230VAC at Max. load

POE125U-

4AT-N

POE75U-

1UP-N

POE240U-

2MP-N

POE240U-

4UP-N

POE576U-

8UP-N

POE576U-

4MP-N

POE806U-

8MP-N

Nominal DC Output Voltage

56V

Output Power per Port

33.6W

75W

95W

60W

75W

95W

Maximum Current per Port

0.6A

1.339A

1.696A

1.071A

1.339A

1.696A

POE125U-

4AT-N

POE75U-

1UP-N

POE240U-

2MP-N

POE240U-

4UP-N

POE576U-

8UP-N

POE576U-

4MP-N

POE806U-

8MP-N

25K

12.5K and 25K (both)

•

Detection Resistance

•

Output

For detailed speciﬁcations, refer to the datasheets posted on www.phihong.com or www.midspans.

com
