Data Sheet
HMC554ALC3B
Rev. A | Page 23 of 26
SPURIOUS AND HARMONICS PERFORMANCE
Mixer spurious products are measured in dBc from the IF output
power level. N/A means not applicable.
LO Harmonics
LO = 13 dBm, all values in dBc below input LO level and
measured at RF port.
Table 5. LO Harmonics at RF
N × LO Spur at RF Port
LO Frequency (GHz)
1
2
3
4
12
39
39
59
57
13
38
40
70
N/A
15
38
48
49
N/A
16
37
56
50
N/A
18
36
54
N/A
N/A
19
36
53
N/A
N/A
21
36
46
N/A
N/A
LO = 13 dBm, all values in dBc below input LO level and
measured at IF port.
Table 6. LO Harmonics at IF
N × LO Spur at IF Port
LO Frequency (GHz)
1
2
3
4
12
38
77
67
89
13
41
63
74
N/A
15
44
72
56
N/A
16
42
53
56
N/A
18
44
79
N/A
N/A
19
53
70
N/A
N/A
21
47
75
N/A
N/A
M × N Spurious Outputs
Downconverter, Upper Sideband
Spur values are (M × RF) − (N × LO).
RF = 15.1 GHz at −10 dBm, LO = 15 GHz at 13 dBm.
N × LO
0
1
2
3
4
5
M × RF
0
N/A
14
47
27
N/A
N/A
1
48
0
70
72
65
N/A
2
75
77
60
79
74
68
3
65
74
79
70
78
71
4
N/A
60
74
80
88
78
5
N/A
N/A
56
72
81
88
Upconverter, Upper Sideband
Spur values are (M × IF) + (N × LO).
IFIN = 100 MHz at −10 dBm, LO = 15 GHz at 13 dBm.
N × LO
0
1
2
3
M × IF
−5
89
80
73
67
−4
88
79
73
68
−3
91
66
74
66
−2
91
67
74
66
−1
36
0
35
20
0
N/A
6
17
22
+1
36
0
35
19
+2
88
63
73
65
+3
90
63
74
66
+4
90
80
73
65
+5
88
78
72
66
