background image
www.knowlescapacitors.com
28
Part
Number
Cap Range
(pF)
Min. Q @
175 MHz
Dimensions
Fig.
A
B
C
D
E
F
G
52H01
52H02
1.5 to 10.0
>1400*
0.31
0.22
.295
.275
0.31
-
-
-
0.06
-
0.09
1
2
55H01
1.5 to 19.0
>1000
0.31
0.22
.295
.275
0.31
-
-
-
1
55H02
1.5 to 19.0
>1000
0.31
0.22
.295
.275
-
-
0.06
0.09
2
80H85
1.5 to 19.0
>1000
0.31
0.22
.295
.275
0.32
-
0.125
-
2
Notes: Dimensions (inches). *Q @ 195MHz.
High Voltage Trimmers
Characteristics
Rated voltage:
1250 VDC - test voltage 2500 VDC (52H02)
1000 VDC - test voltage 2000 VDC (55H01) (55H02) (80H85)
Q >1400@ 195 MHz (52H02)
Q >1000@ 175 MHz (55H01) (55H02) (80H85)
Insulation resistance: >106 MΩ
Operating temperature range: -65°C to +125°C
Torque: 1 to 10 oz. in.
Contact resistance: <.01 Ω
Figure 1
Figure 2
Figure 3
Recommended Tuning Tool
JMC 8764
