31 / 60 page  www.knowlescapacitors.com 29 Giga-Trim® Trimmers - Description Sapphire dielectric Ceramic dielectric Zirconia High K dielectric High Q 500 VDC working voltage Select part numbers available on tape and reel Utilizes the same constant torque drive mechanism as Johanson air capacitors and tuning elements Characteristics Rated voltage: 500 VDC Insulation resistance: >106 MΩ @ 500 VDC Rotational life exceeds Mil-C-14409 Contact resistance: <.01 V Operating temperature: -65°C to +125°C Self resonant frequency: >12 GHz Vibration: 60g, 10-2000 Hz Shock: 100g, 6 milliseconds Applications Impedance matching Crystal trimming Interstage coupling Base station amplifier Seal Caps Type Part No. Cap type Material 17273 P4446-2 “Poke-Thru” Seal Cap Teflon® 27260 Thru 27265 P4445-1 Standard Seal Cap Teflon® 27270 Thru 27295 P4445 Standard Seal Cap Teflon® 27260 Thru 27265 P4446-1 “Poke-Thru” Seal Cap Teflon® 27270 Thru 27295 P4446 “Poke-Thru” Seal Cap Teflon® 47273 Thru 47285 P4446-2 “Poke-Thru” Seal Cap Teflon® 57263 P4446-1 “Poke-Thru” Seal Cap Teflon® Note: The use of a Johanson tuning tool is recommended. Improper screwdriver size will cause internal thread damage. JMC 8762 JMC Drive Tuning Tool 8762 JMC Drive Tuning Tool 8766 JMC 8766 Q Frequency (MHz) 10000 1000 100 10 0 250 500 750 1000 1250 1500 1750 2000 2250 2500 27260 27270 27280 27290 Set at Max. capacitance |
|
