41 / 60 page  www.knowlescapacitors.com 39 Glass Annular Band Capacitance Range (pF) Q (Min.) UNSEALED 750 DCWV (Fig. 1) SEALED, METAL CAP, TURRET TERMINAL 750 DCWV (Fig. 2) SEALED, GLASS END 1,250 DCWV (Fig. 3) From below To above 1 MHz A±.03 Type MIL Designation A±.03 Type A±.03 Type MIL Designation 0.8 4.5 650 .31 TM5 PC40J4R5** .41 TM5C .36 TM5G PC38J4R5** 0.8 5.5 700 .31 TM6 P050J5R5 .41 TM6C .36 TM6G PC48J5R5 0.8 8.5 650 .55 TM9 PC40J8R5** .63 TM9C .59 TM9G PC38J8R5** 1.0 11.0 700 .55 TM11 PC50J110 .63 TM11C .59 TM11G PC48J11O 0.8 12.0 650 .75 TM12 PC40H120** .83 TM12C .81 TM12G PC38H120** 0.8 16.0 700 .75 TM17 PC50H160 .83 TM17C .81 TM17G PC48H160 0.8 18.0 650 1.00 TM18 PC40H180** 1.09 TM18C 1.06 TM18G PC38H180** 0.8 21.0 700 1.13 TM21 — 1.22 TM21C — — — 0.8 23.0 700 1.00 TM23 PC50H230 1.09 TM23C 1.06 TM23G PC48H230 0.8 30.0 650 1.59 TM30 PC40H300** 1.69 TM30C 1.66 1M30G PC38H300** 0.8 38.0 700 1.59 TM38 PC50H380 1.69 TM38C 1.66 TM38G PC48H380 Glass Embedded Band Capacitance Range (pF) Q (Min.) UNSEALED 1,000 DCWV (Fig. 1) SEALED, METAL CAP, TURRET TERMINAL 1,000 DCWV (Fig. 2) SEALED, METAL CAP, 1,000 DCWV (Fig. 4) From below To above 1 MHz A±.016 Type A±.03 Type MIL Designation A±.03 Type 2.0 10.0 800 .28 TM10* .37 TM10C* — .35 TM10M* 1.5 14.0 700 .38 TM14 .47 TM14C — .45 TM14M 1.2 16.0 800 .33 TM15* .42 TM15C* — .40 TM15M* 1.0 16.0 800 .38 TM16 .47 TM16C PC39G160 .45 TM16M 2.0 25.0 800 .42 TM25 .52 TM25C — .50 TM25M 1.0 28.0 700 .61 TM28 .70 TM28C — .69 TM28M 1.0 36.0 800 .61 TM36 .70 TM36C PC39G360 .69 TM36M 1.0 42.0 700 .83 TM42 .92 TM42C — .91 TM42M 1.0 52.0 800 .83 TM52 .92 TM52C PC39G520 .91 TM52M 1.0 60.0 650 1.08 TM60 1.17 TM60C — 1.16 TM60M 1.0 75.0 700 1.08 TM75 1.17 TM75C PC39G750 1.16 TM75M 1.0 90.0 600 1.67 TM90 1.77 TM90C — 1.75 TM90M 1.0 120.0 600 1.67 TM120 1.77 TM120C P039G121 1.75 TM120M 2.0 180.0 500 1.91 TM180* 2.00 TM180C* — 1.98 TM180M* Quartz Capacitance Range (pF) Q (Min.) UNSEALED 750 DCWV (Fig. 1) SEALED, QUARTZ END 1,250 DCWV (Fig. 3) From below To above 1 MHz A±.03 Type MIL Designation A±.03 Type MIL Designation 0.6 1.8 2000 .30 QM2 PC40Q1R8 .36 QM2G PC38Q1R8 0.8 5.5 2000 .55 QM6 P040Q5R5 .63 QM6G PC38Q5R5 0.6 9.5 2000 .98 QM10 PC40Q9R5 1.06 QM10G PC38Q9R5 0.8 16.0 2000 1.59 QM16 PC40Q160 1.66 QM16G PC38Q160 *Parts Rated 500 DCWV **MIL-C-14409B parts not listed in MIL-C-14409D Panel Mount Trimmers - TM & QM Series a Knowles Precision Devices brand TM |
|
