–5–

REV. F

AD8009

FREQUENCY (MHz)

100

–1

–6

–7

–2

–3

–4

–5

1000

R PACKAGE:

RL = 100

VO = 200mV p–p

G = +1, +2: RF = 301

G = +10: RF = 200

RT PACKAGE:

G = +1: RF = 332

G = +2: RF = 226

G = +10: RF = 191

G = +1, R

G = +10, R AND RT

G = +2, R AND RT

G = +1, RT

TPC 1. Frequency Response; G = +1, +2, +10,

R and RT Packages

–1

–2

100

1000

FREQUENCY (MHz)

G = +2

RF = 301

RL = 150

VO AS SHOWN

4V p-p

2V p-p

TPC 2. Large Signal Frequency Response; G = +2

–1

–2

100

1000

FREQUENCY (MHz)

G = +2

RF = 301

RL = 150

VO = 2V p–p

–40 C

+85 C

–40 C

+85 C

TPC 3. Large Signal Frequency Response vs.

Temperature; G = +2

6.1

6.0

5.9

5.8

5.7

5.6

5.5

5.4

5.3

5.2

6.2

FREQUENCY (MHz)

100

1000

G = +2

RF = 301

RL = 150

VO = 200mV p-p

TPC 4. Gain Flatness; G = +2

FREQUENCY (MHz)

–0.3

–0.2

–0.1

0.1

0.2

0.3

0.4

110

100

1000

10000

G = +2

RF = 301

RL = 150

VO = 200mV p-p

VS = 5V

TPC 5. Gain Flatness; G = +2; VS = 5 V

100

1000

FREQUENCY (MHz)

G = +10

RF = 200

RL = 100

VO AS SHOWN

2V p-p

4V p-p

TPC 6. Large Signal Frequency Response; G = +10

Typical Performance Characteristics–
