–9–
REV. F
AD8009
2.0
1.8
1.6
1.4
1.2
1.0
0
2.2
FREQUENCY (MHz)
0.1
1
100
10
C
COMP = 0pF
C
COMP = 3pF
200
49.9
C
COMP
49.9
22.1
500
TPC 25. Output VSWR; G = +10
10
0%
100
90
VOUT
VIN = 2VSTEP
250ns
2V
2V
G = +10
RF = 200
RL = 100
TPC 26. Overdrive Recovery; G = +10
1ns
50mV
G = +2
RF = 301
RL = 150
VO = 200mV p-p
TPC 27. 2 V Transient Response; G = +2
1ns
500mV
G = +2
RF = 301
RL = 150
VO = 2V p-p
TPC 28. 2 V Transient Response; G = +2
1.5ns
1V
G = +2
RF = 301
RL = 150
VO = 4V p-p
TPC 29. 4 V Transient Response; G = +2
2ns
50mV
G = +10
RF = 200
RL = 100
VO = 200mV p-p
TPC 30. Small Signal Transient Response; G = +10
