–3–

REV. F

AD8009

SPECIFICATIONS

(@ TA = 25 C, VS =

5 V, RL = 100

, for R Package: RF = 301

for G = +1, +2,

RF = 200

for G = +10).

AD8009AR/JRT

Model

Conditions

Min

Typ

Max

Unit

DYNAMIC PERFORMANCE

–3 dB Small Signal Bandwidth, VO = 0.2 V p-p

G = +1, RF = 301

Ω

630

MHz

G = +2

430

MHz

G = +10

300

MHz

Large Signal Bandwidth, VO = 2 V p-p

G = +2

365

MHz

G = +10

250

MHz

Gain Flatness 0.1 dB, VO = 0.2 V p-p

G = +2, RL = 150

Ω

MHz

Slew Rate

G = +2, RL = 150

Ω, 4 V Step

2,100

µs

Settling Time to 0.1%

G = +2, RL = 150

Ω, 2 V Step

G = +10, 2 V Step

Rise and Fall Time

G = +2, RL = 150

Ω, 4 V Step

0.725

HARMONIC/NOISE PERFORMANCE

Second Harmonic G = +2, VO = 2 V p-p

10 MHz

–74

dBc

20 MHz

–67

dBc

70 MHz

–48

dBc

Third Harmonic

10 MHz

–76

dBc

20 MHz

–72

dBc

70 MHz

–44

dBc

Input Voltage Noise

f = 10 MHz

1.9

nV/

√Hz

Input Current Noise

f = 10 MHz, +In

pA/

√Hz

f = 10 MHz, –In

pA/

√Hz

DC PERFORMANCE

Input Offset Voltage

–Input Bias Current

150

±µA

+Input Bias Voltage

150

±µA

INPUT CHARACTERISTICS

Input Resistance

+Input

110

Ω

–Input

Ω

Input Capacitance

+Input

2.6

Input Common-Mode Voltage Range

1.2 to 3.8

Common-Mode Rejection Ratio

VCM = 1.5 V to 3.5 V

OUTPUT CHARACTERISTICS

Output Voltage Swing

1.1 to 3.9

Output Current

RL = 10

Ω, PD Package = 0.7 W

175

Short-Circuit Current

330

POWER SUPPLY

Operating Range

±6V

Quiescent Current

Power Supply Rejection Ratio

VS = 4.5 V to 5.5 V

Specifications subject to change without notice.
