E39-R1 Scheda tecnica(PDF) 76 Page - Omron Electronics LLC |
|
|
|||||||||||||||||||||||||||||
E39-R1 Scheda tecnica(HTML) 76 Page - Omron Electronics LLC |
|
|
76 / 100 page  Fiber Amplifiers, Communications Unit and Accessories E3NW Fiber Amplifiers, Communications Unit and Accessories E3NW 76 Threaded Cylindrical Flat Sleeved Small Spot High Power Retro- reflective Limited- reflective Narrow view BGS Chemical- resistant, Oil-resistant Bending Heat- resistant Area Detection Liquid-level Vacuum FPD, Semi, Solar Installation Information 77 Installation Information Threaded Cylindrical Flat Sleeved Small Spot High Power Retro- reflective Limited- reflective Narrow view BGS Chemical- resistant, Oil-resistant Bending Heat- resistant Area Detection Liquid-level Vacuum FPD, Semi, Solar 76 77 E3NW-ECT 77-A Ratings and Specifications Communications Specifications Item Models Power supply voltage Indicators Ambient temperature range Insulation resistance Vibration resistance (destruction) Maximum connectable Sensors Shock resistance (destruction) Connectable Sensor Amplifier Units Power and current consumption 2.4 W max. (Not including the power supplied to Sensor.) 100 mA max. (Not including the current supplied to Sensor.) 2 W max. (Not including the power supplied to Sensor.) 80 mA max. (Not including the current supplied to Sensor.) 10 to 60 Hz with a 0.7-mm double amplitude, 60 to 150 Hz 50 m/s2 for 1.5 hours each in X, Y, and Z directions Destruction: 150 m/s2 for 3 times each in X, Y, and Z directions N-Smart Smart Fiber Amplifier Unit: Color Fiber Amplifier Unit: Smart Laser Amplifier Unit: Smart Laser Amplifier Unit (CMOS type): Contact-Type Smart Amplifier Unit: E3NX-FA0 E3NX-CA0 *1 E3NC-LA0 E3NC-SA0 E9NC-TA0 *2 L/A IN Indicator (Green), L/A OUT Indicator (Green), PWR Indicator (Green), RUN Indicator (Green), ERROR Indicator (Red),and SS (Sensor Status) indicator (Green/Red) RUN Indicator (Green), and SS (Sensor Status) indicator (Green/Red) 24VDC (20.4 to 26.4 VDC) Operating: 0 to 55°C, *3 Storage: −30 to 70°C (with no icing or condensation) Ambient humidity range Operating and storage: 25% to 85% (with no condensation) 20 MΩ min. (at 500 VDC) Dielectric strength 500 VAC 50/60Hz 1 min Mounting method 35-mm DIN track-mounting Weight (packed state/unit only) Approx. 185 g/Approx. 95 g Approx. 160 g/Approx. 40 g Materials Polycarbonate Accessories Power supply connector,Communications connector for E3NW-DS, DIN Track End Plates (2) and Instruction manual Power supply/communications connector, DIN Track End Plates (2), Ferrite cores (2) and Instruction manual 30 *4 Maximum connectable Distributed Sensor units 8 ― 10 *1. The E3NX-CA0 is supported for firmware version 1.06 or higher (Sensor Communications Units manufactured in June 2016 or later). *2. The E9NC-TA0 is supported for firmware version 1.03 or higher (Sensor Communications Units manufactured in July 2014 or later). *3. Temperature Limitations Based on Number of Connected Amplifier Units: Groups of 1 or 2 Amplifiers: 0 to 55°C, Groups of 3 to 10 Amplifiers: 0 to 50°C, Groups of 11 to 16 Amplifiers: 0 to 45°C, Groups of 17 to 30 Amplifiers: 0 to 40°C *4. A maximum total of 30 Sensors can be connected to a Sensor Communications Unit and Distributed Sensor Units. *1. The software setting is used when the node address setting switches are set to 0. *2. The range depend on the EtherCAT master that is used. Refer to the E3NW-ECT EtherCAT Sensor Communications Unit Operation Manual for details. Item Protocol Specifications EtherCAT Modulation Baseband Baud rate 100 Mbps Physical layer 100Base-TX (IEEE802.3u) Topology Daisy chain Communications media STP category 5 or higher Communications distance 100 m max. between nodes Noise immunity Compliant with IEC 61000-4-4, 1 kV min. Node address setting method Set the decimal rotary switches or software *1 Node address range 000 to 192 *2 Sensor Communications Unit E3NW-DS 77-B Distributed Sensor Unit Dimensions (Unit: mm) Tolerance class IT16 applies to demmensions in this date sheet unless otherwise specified. E3NW-DS E3NW-ECT CompoNet-compatible and CC-Link-compatible products are also available. Refer to your OMRON website for details. Connector: Provided. (FK-MCP 1,5/4-STF-3,5 AU) 20 Connector cover 95.7 49 69 (34.3) (44.5) 25.4 (42.9) 30.4 DIN Track (sold separately) (PFP- N) 13.5 9.5 18 105.1 41 32.5 102.5 60.9 15.4 86.6 64.5 10 10 (36.7) (49.8) 32.2 (43) 38.8 Power Supply Connector (provided) (FK-MCP 1,5/2-STF-3,5 AU) Communications Connector (provided) (FK-MCP 1,5/2-STF-3,5 AU) Input communications connector Output communications connector Connector cover PFP- N DIN Track (sold separately) |
|
