Fiber Amplifiers, Communications Unit and Accessories

Accessories (sold separately)

Fiber Amplifiers, Communications Unit and Accessories

Accessories (sold separately)

Threaded

Cylindrical

Flat

Sleeved

Small Spot

High Power

Retro-

reflective

Limited-

reflective

Narrow

view

BGS

Chemical-

resistant,

Oil-resistant

Bending

Heat-

resistant

Area

Detection

Liquid-level

Vacuum

FPD,

Semi,

Solar

Installation

Information

Installation

Information

Threaded

Cylindrical

Flat

Sleeved

Small Spot

High Power

Retro-

reflective

Limited-

reflective

Narrow

view

BGS

Chemical-

resistant,

Oil-resistant

Bending

Heat-

resistant

Area

Detection

Liquid-level

Vacuum

FPD,

Semi,

Solar

Master Connector

Slave Connector

E39-L143

Mounting Brackets

PFP-M

End Plate

PFP-100N

PFP-50N

PFP-100N2

DIN track

Four-R1.7

3.4

10 max. 7

10.3

7.3

5.3

(10.3)

2.5

34.8

26.8

Two-3.2 dia.

3.4

Two-M3

16±0.1

Mounting Holes

11.5

M4 × 8

panhead screw

M4 spring washer

4.8

1.3

1.8

6.2 10

35.5

35.3

89-A

89-D

89-B

89-C

88-A

88-B

E3X-CN21

E3X-CN11

E3X-CN22

E3X-CN12

Sensor I/O Connectors (for Models with M8 Connectors)

88-C

XS3F-M421-402-A

XS3F-M421-405-A

88-D

XS3F-M422-402-A

XS3F-M422-405-A

Wire-saving Connectors

Wire-saving Connectors (for Models with Wire-saving Connectors)

Ratings and Specifications

Models

Type

Item

Rated current

Rated voltage

Housing

Contact

Weight (packed state)

Number of conductors

Diameter of cable

Contact resistance

Number of insertions

Material

E3X-CN21

E3X-CN11

E3X-CN22

E3X-CN12

Master Connector

Slave Connector

20 mΩ max. (20 mVDC max., 100 mA max.)

(The above figure is for connection to the Amplifier Unit and the adjacent Connector.

It does not include the conductor resistance of the cable.)

Destruction: 50 times (for connection to the Amplifier Unit and the adjacent Connector)

Polybutylene terephthalate (PBT)

Phosphor bronze/gold-plated nickel

Approx. 55 g

2.5A

50VDC

Approx. 25 g

4 dia.

2.6 dia.

Sensor I/O Connectors

Models

Item

Rated current

Rated voltage

Number of conductors

Diameter of cable

Contact resistance

Number of insertions

XS3F-M42 -40 -A

40 mΩ max.

(20 mVDC max., 100 mA max.)

Destruction: 200 times

125VDC

4 dia.

(7)

2,000

See note

Edge of amplifier

Note: E3X-CN21 : 4 dia. cable / 4 conductors / Standard length: 2 m

(Conductor cross section: 0.2 mm2 (AWG24), Insulator diameter: 1.1 mm)

E3X-CN11 : 4 dia. cable / 3 conductors / Standard length: 2 m

(Conductor cross section: 0.2 mm2 (AWG24), Insulator diameter: 1.1 mm)

Note: E3X-CN22 : 4 dia. cable / 2 conductors / Standard length: 2 m

(Conductor cross section: 0.2 mm2 (AWG24), Insulator diameter: 1.1 mm)

E3X-CN12 : 2.6 dia. cable / 1 conductor / Standard length: 2 m

(Conductor cross section: 0.2 mm2 (AWG24), Insulator diameter: 1.1 mm)

2,000

(7)

See note

Edge of amplifier

Material: Stainless steel (SUS304)

Material: Aluminum

Material: Iron, zinc plating

4.5

15 25

1,000 (500)

(See note)

15 (5)

(See note)

35±0.3

7.3±0.15

27±0.15

Note: The figures in parenthesses are for the PFP-50N.

4.5

15 25

1,000

25 15

1.5

29.2

35±0.3

4 dia.

1.95

0.5

3.4

2.15

20.5

dia.

23.1

4 dia.

9 dia.

1.95 0.5

3.4

2.15 M8

31.4

21.5

12.9

Models

Cable length L (m)

XS3F-M42 -402-A

XS3F-M42 -405-A

Dimensions

(Unit: mm)

Tolerance class IT16 applies to demmensions in this date sheet unless otherwise specified.
