background image
Table 16. DC characteristics (M95256-W, device grade 6)
Symbol
Parameter
Test conditions
Min.
Max.
Unit
ILI
Input leakage current
VIN = VSS or VCC
-
± 2
µA
ILO
Output leakage current
S = VCC, Q = VSS or VCC
-
± 2
µA
ICC
Supply current (Read)
VCC = 2.5 V, C = 0.1 VCC / 0.9 VCC
at 10 MHz, Q = open
-
2
mA
VCC = 5.5 V, C = 0.1 VCC / 0.9 VCC
at 20 MHz, Q = open
-
5
mA
ICC0 (1)
Supply current (Write)
During tW, S = VCC,
2.5 V ≤ VCC ≤ 5.5 V
-
5
mA
ICC1
Supply current
(Standby Power mode)
S = VCC, VCC= 2.5 V,
VIN = VSS or VCC
-
2
µA
S = VCC, VCC= 5.5 V,
VIN = VSS or VCC
-
3
µA
VIL
Input low voltage
-
–0.45
0.3 VCC
V
VIH
Input high voltage
-
0.7 VCC
VCC+1
V
VOL
Output low voltage
VCC = 2.5 V and IOL = 1.5 mA or
VCC = 5 V and IOL = 2 mA
-
0.4
V
VOH
Output high voltage
VCC = 2.5 V and IOH = –0.4 mA or
VCC = 5 V and IOH = –2 mA
0.8 VCC
-
V
1. Evaluated By Characterization - Not tested in production.
Table 17. DC characteristics (M95256-R, device grade 6)
Symbol
Parameter
Test conditions(1)
Min
Max
Unit
ILI
Input leakage current
VIN = VSS or VCC
-
± 2
µA
ILO
Output leakage current
S = VCC, Q = VSS or VCC
-
± 2
µA
ICC
Supply current (Read)
VCC= 1.8 V, C = 0.1 VCC / 0.9 VCC
at 5 MHz, Q = open
-
2
mA
ICC0 (2) Supply current (Write)
VCC = 1.8 V , during tW, S = VCC
-
3
mA
ICC1
Supply current (Standby Power mode)
VCC = 1.8 V, S = VCC, VIN = VSS or VCC
-
1
µA
VIL
Input low voltage
1.8 V ≤ VCC < 2.5 V
– 0.45
0.25 VCC
V
VIH
Input high voltage
1.8 V ≤ VCC < 2.5 V
0.75 VCC
VCC+1
V
VOL
Output low voltage
IOL = 0.15 mA, VCC = 1.8 V
-
0.3
V
VOH
Output high voltage
IOH = –0.1 mA, VCC = 1.8 V
0.8 VCC
-
V
1. If the application uses the M95256-R with 2.5 V < VCC < 5.5 V and - 40 °C < TA < + 85 °C, refer to Table 16. DC
characteristics (M95256-W, device grade 6) instead of the above table.
2. Evaluated By Characterization - Not tested in production.
M95256-W M95256-R M95256-DF
DC and AC parameters
DS4712 - Rev 22
page 30/51
