31 / 51 page

Table 18. DC characteristics (M95256-DF, device grade 6)

Symbol

Parameter

Test conditions(1)

Min.

Max.

Unit

ILI

Input leakage current

VIN = VSS or VCC

± 2

µA

ILO

Output leakage current

S = VCC, Q = VSS or VCC

± 2

µA

ICC

Supply current (Read)

VCC = 1.7 V, C = 0.1 VCC / 0.9 VCC,

at 5 MHz, Q = open

ICC0(2)

Supply current (Write)

VCC = 1.7 V, during tW, S = VCC

ICC1

Supply current (Standby)

VCC = 1.7 V, S = VCC, VIN = VSS or VCC

µA

VIL

Input low voltage

1.7 V ≤ VCC < 2.5 V

– 0.45

0.25 VCC

VIH

Input high voltage

1.7 V ≤ VCC < 2.5 V

0.75 VCC

VCC+1

VOL

Output low voltage

IOL = 0.15 mA, VCC = 1.7 V

0.3

VOH

Output high voltage

IOH = –0.1 mA, VCC = 1.7 V

0.8 VCC

1. If the application uses the M95256-DF devices at 2.5 V ≤ VCC ≤ 5.5 V and –40 °C ≤ TA ≤ +85 °C, refer to

Table 16. DC characteristics (M95256-W, device grade 6), rather than to the above table.

2. Evaluated By Characterization - Not tested in production.

M95256-W M95256-R M95256-DF

DC and AC parameters

DS4712 - Rev 22

page 31/51
