Data Sheet

ADL8106

ELECTRICAL SPECIFICATIONS

analog.com

Rev. B | 4 of 26

30 GHZ TO 44 GHZ FREQUENCY RANGE

TCASE = 25°C, VDD1 = VDD2 = 3 V, and IDQ = 120 mA, unless otherwise stated. Adjust VGG1 between −2 V to 0 V to achieve an IDQ = 120 mA

typical.

Table 3.

Parameter

Min

Typ

Max

Unit

Test Conditions/Comments

FREQUENCY RANGE

30

44

GHz

GAIN

19

21.5

dB

Gain Variation over Temperature

0.028

dB/°C

RETURN LOSS

Input

12.5

dB

Output

19

dB

OUTPUT

OP1dB

12

14.5

dBm

PSAT

19

dBm

OIP3

21.5

dBm

POUT per tone = 0 dBm with 1 MHz tone spacing

NOISE FIGURE

3.5

dB

SUPPLY

IDQ

120

mA

Adjust VGG1 to achieve IDQ = 120 mA typical

VDD

2

3

3.5

V

44 GHZ TO 50 GHZ FREQUENCY RANGE

TCASE = 25°C, VDD1 = VDD2 = 3 V, and IDQ = 120 mA, unless otherwise stated. Adjust VGG1 between −2 V to 0 V to achieve an IDQ = 120 mA

typical.

Table 4.

Parameter

Min

Typ

Max

Unit

Test Conditions/Comments

FREQUENCY RANGE

44

50

GHz

GAIN

22

dB

Gain Variation over Temperature

0.031

dB/°C

RETURN LOSS

Input

15

dB

Output

18

dB

OUTPUT

OP1dB

16.5

dBm

PSAT

20.5

dBm

OIP3

22

dBm

POUT per tone = 0 dBm with 1 MHz tone spacing

NOISE FIGURE

4

dB

SUPPLY

IDQ

120

mA

Adjust VGG1 to achieve IDQ = 120 mA typical

VDD

2

3

3.5

V
