TDA4VEN...Q1 Scheda tecnica(PDF) 33 Page - Texas Instruments |
|
|
|||||||||||||||||||||||||||||
TDA4VEN...Q1 Scheda tecnica(HTML) 33 Page - Texas Instruments |
|
|
33 / 236 page  Table 5-1. Pin Attributes (AMW Package) (continued) BALL NUMBER [1] BALL NAME [2] PADCONFIG Register [15] PADCONFIG Address [16] SIGNAL NAME [3] MUX MODE [4] TYPE [5] DSIS [6] BALL STATE DURING RESET (RX/TX/PULL) [7] BALL STATE AFTER RESET (RX/TX/PULL) [8] MUX MODE AFTER RESET [9] I/O OPERATING VOLTAGE [10] POWER [11] HYS [12] BUFFER TYPE [13] PULL UP/DOWN TYPE [14] K22 OSPI0_CSn2 PADCONFIG PADCONFIG13 0x000F4034 OSPI0_CSn2 0 O Off / Off / Off Off / Off / Off 7 1.8 V/3.3 V VDDSHV1 Yes LVCMOS PU/PD SPI1_CS1 1 IO 1 OSPI0_RESET_OUT1 2 O MCASP1_AFSR 3 IO 0 MCASP1_AXR2 4 IO 0 UART5_RXD 5 I 1 GPIO0_13 7 IO pad J22 OSPI0_CSn3 PADCONFIG PADCONFIG14 0x000F4038 OSPI0_CSn3 0 O Off / Off / Off Off / Off / Off 7 1.8 V/3.3 V VDDSHV1 Yes LVCMOS PU/PD OSPI0_RESET_OUT0 1 O OSPI0_ECC_FAIL 2 I 1 MCASP1_ACLKR 3 IO 0 MCASP1_AXR3 4 IO 0 UART5_TXD 5 O GPIO0_14 7 IO pad K27 OSPI0_D0 PADCONFIG PADCONFIG3 0x000F400C OSPI0_D0 0 IO 0 Off / Off / Off Off / Off / Off 7 1.8 V/3.3 V VDDSHV1 Yes LVCMOS PU/PD GPIO0_3 7 IO pad L27 OSPI0_D1 PADCONFIG PADCONFIG4 0x000F4010 OSPI0_D1 0 IO 0 Off / Off / Off Off / Off / Off 7 1.8 V/3.3 V VDDSHV1 Yes LVCMOS PU/PD GPIO0_4 7 IO pad L26 OSPI0_D2 PADCONFIG PADCONFIG5 0x000F4014 OSPI0_D2 0 IO 0 Off / Off / Off Off / Off / Off 7 1.8 V/3.3 V VDDSHV1 Yes LVCMOS PU/PD GPIO0_5 7 IO pad L25 OSPI0_D3 PADCONFIG PADCONFIG6 0x000F4018 OSPI0_D3 0 IO 0 Off / Off / Off Off / Off / Off 7 1.8 V/3.3 V VDDSHV1 Yes LVCMOS PU/PD GPIO0_6 7 IO pad L21 OSPI0_D4 PADCONFIG PADCONFIG7 0x000F401C OSPI0_D4 0 IO 0 Off / Off / Off Off / Off / Off 7 1.8 V/3.3 V VDDSHV1 Yes LVCMOS PU/PD SPI1_CS0 1 IO 1 MCASP1_AXR1 2 IO 0 UART6_RXD 3 I 1 GPIO0_7 7 IO pad M26 OSPI0_D5 PADCONFIG PADCONFIG8 0x000F4020 OSPI0_D5 0 IO 0 Off / Off / Off Off / Off / Off 7 1.8 V/3.3 V VDDSHV1 Yes LVCMOS PU/PD SPI1_CLK 1 IO 0 MCASP1_AXR0 2 IO 0 UART6_TXD 3 O GPIO0_8 7 IO pad www.ti.com TDA4VEN-Q1, TDA4AEN-Q1 SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024 Copyright © 2024 Texas Instruments Incorporated Submit Document Feedback 33 Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1 |
|
