Table 5-32. I2C2 Signal Descriptions
SIGNAL NAME [1]
PIN TYPE
[2]
DESCRIPTION [3]
AMW PIN [4]
I2C2_SCL
IOD
I2C Clock
G26, P22
I2C2_SDA
IOD
I2C Data
G27, H27, P23
Table 5-33. I2C3 Signal Descriptions
SIGNAL NAME [1]
PIN TYPE
[2]
DESCRIPTION [3]
AMW PIN [4]
I2C3_SCL
IOD
I2C Clock
E22, H26
I2C3_SDA
IOD
I2C Data
B21, F27
Table 5-34. I2C4 Signal Descriptions
SIGNAL NAME [1]
PIN TYPE
[2]
DESCRIPTION [3]
AMW PIN [4]
I2C4_SCL
IOD
I2C Clock
D22, R27
I2C4_SDA
IOD
I2C Data
C22, P21
5.3.13.2 MCU Domain
Table 5-35. MCU_I2C0 Signal Descriptions
SIGNAL NAME [1]
PIN TYPE
[2]
DESCRIPTION [3]
AMW PIN [4]
MCU_I2C0_SCL
IOD
I2C Clock
B13
MCU_I2C0_SDA
IOD
I2C Data
E11
5.3.13.3 WKUP Domain
Table 5-36. WKUP_I2C0 Signal Descriptions
SIGNAL NAME [1]
PIN TYPE
[2]
DESCRIPTION [3]
AMW PIN [4]
WKUP_I2C0_SCL
IOD
I2C Clock
B9
WKUP_I2C0_SDA
IOD
I2C Data
D11
5.3.14 MCAN
5.3.14.1 MAIN Domain
Table 5-37. MCAN0 Signal Descriptions
SIGNAL NAME [1]
PIN TYPE
[2]
DESCRIPTION [3]
AMW PIN [4]
MCAN0_RX
I
MCAN Receive Data
C22
MCAN0_TX
O
MCAN Transmit Data
D22
Table 5-38. MCAN1 Signal Descriptions
SIGNAL NAME [1]
PIN TYPE
[2]
DESCRIPTION [3]
AMW PIN [4]
MCAN1_RX
I
MCAN Receive Data
A24, J23, P23
MCAN1_TX
O
MCAN Transmit Data
B24, H25, P22
www.ti.com
TDA4VEN-Q1, TDA4AEN-Q1
SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024
Copyright © 2024 Texas Instruments Incorporated
Submit Document Feedback
63
Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1
