TDA4VEN...Q1 Scheda tecnica(PDF) 95 Page - Texas Instruments |
|
|
|||||||||||||||||||||||||||||
TDA4VEN...Q1 Scheda tecnica(HTML) 95 Page - Texas Instruments |
|
|
95 / 236 page  6.9.2 Power Supply Requirements This section describes the power supply requirements to ensure proper device operation. Note All power balls must be supplied with the voltages specified in the Recommended Operating Conditions section, unless otherwise specified in Signal Descriptions and Pin Connectivity Requirements. 6.9.2.1 Power Supply Slew Rate Requirement To maintain the safe operating range of the internal ESD protection devices, TI recommends limiting the maximum slew rate of supplies to be less than 18mV/µs. For instance, as shown in Figure 6-2, TI recommends having the supply ramp slew for a 1.8V supply of more than 100µs. Figure 6-2 describes the Power Supply Slew Rate Requirement in the device. t slew rate < 18 mV/ s slew > (supply value) / (18 ) or supply value × 55.6 s/V μ μ μ mV/ s Supply value SPRT740_ELCH_06 Figure 6-2. Power Supply Slew and Slew Rate www.ti.com TDA4VEN-Q1, TDA4AEN-Q1 SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024 Copyright © 2024 Texas Instruments Incorporated Submit Document Feedback 95 Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1 |
|
