9.1.1 Standard Package Symbolization

Note

Some devices may have a cosmetic circular marking visible on the top of the device package which

results from the production test process. In addition, some devices may also show a color variation in

the package substrate which results from the substrate manufacturer. These differences are cosmetic

only with no reliability impact.

(PIN 1 INDICATOR)

TI aBBBBBBB

BZYrc Q1

XXXXXXX

YYY PPP

Figure 9-1. Printed Device Reference

www.ti.com

TDA4VEN-Q1, TDA4AEN-Q1

SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024

Submit Document Feedback

225

Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1
