R31DS0210EU0106 Rev.1.06
Page 34
May 11, 2026
RC193xx Datasheet
4.5.1
OUTPUT_ENABLE
Output Enable Register.
4.5.2
OEB_PIN_READBACK
OEb Pin Read-back Register.
OUTPUT_ENABLE Bit Field Descriptions
Bit Field
Field Name
Field
Type
Default
Value
Description
7
clk7_en
RW
0x1
CLK7 enable.
0 = Output is disabled (low/low)
1 = Output is enabled
6
clk6_en
RW
0x1
CLK6 enable.
0 = Output is disabled (low/low)
1 = Output is enabled
5
clk5_en
RW
0x1
CLK5 enable.
0 = Output is disabled (low/low)
1 = Output is enabled
4
clk4_en
RW
0x1
CLK4 enable.
0 = Output is disabled (low/low)
1 = Output is enabled
3
clk3_en
RW
0x1
CLK3 enable.
0 = Output is disabled (low/low)
1 = Output is enabled
2
clk2_en
RW
0x1
CLK2 enable.
0 = Output is disabled (low/low)
1 = Output is enabled
1
clk1_en
RW
0x1
CLK1 enable.
0 = Output is disabled (low/low)
1 = Output is enabled
0
clk0_en
RW
0x1
CLK0 enable.
0 = Output is disabled (low/low)
1 = Output is enabled
OEB_PIN_READBACK Bit Field Descriptions
Bit Field
Field Name
Field
Type
Default
Value
Description
7
rb_oeb_7
RO
0x0
State of OEb7 pin. The default pin state is 1 if not driven to a 0.
0 = Pin low
1 = Pin high
6
rb_oeb_6
RO
0x0
State of OEb6 pin. The default pin state is 1 if not driven to a 0.
0 = Pin low
1 = Pin high
5
rb_oeb_5
RO
0x0
State of OEb5 pin. The default pin state is 1 if not driven to a 0.
0 = Pin low
1 = Pin high
4
rb_oeb_4
RO
0x0
State of OEb4 pin. The default pin state is 1 if not driven to a 0.
0 = Pin low
1 = Pin high
3
rb_oeb_3
RO
0x0
State of OEb3 pin. The default pin state is 1 if not driven to a 0.
0 = Pin low
1 = Pin high
2
rb_oeb_2
RO
0x0
State of OEb2 pin. The default pin state is 1 if not driven to a 0.
0 = Pin low
1 = Pin high
