 59 / 62 page
background image
Pin 1 ID
6.00 ±0.10
4.20 ±0.10
4.20 ±0.10
6.00 ±0.10
0.35
1
12
13
24
36
25
37
48
0.40 ±0.10
0.20
0.40
0.90 ±0.10
0.05 Max.
(0.20)
Seating Plane
0.08 C
C
0.35
4.20
4.20
6.30
0.20
0.40
5.20 6.30
Package
Outline
(PCB Top View, NSMD Design)
RECOMMENDED LAND PATTERN
SIDE VIEW
TOP VIEW
BOTTOM VIEW
NOTES:
1.
JEDEC compatible.
2.
All dimensions are in mm and angles are in degrees.
3.
Use ±0.05 mm for the non-toleranced dimensions.
4.
Numbers in ( ) are for references only.
© Renesas Electronics Corporation
Package Outline Drawing
Package Code:NDG48P2
48-VFQFPN 6.0 x 6.0 x 0.9 mm Body, 0.4mm Pitch
PSC-4212-02, Revision: 04, Date Created: Sep 28, 2022
