 61 / 62 page
background image
(PCB Top View, NSMD Design)
Seating Plane
3.00 ±0.10
3.00 ±0.10
Pin 1 ID
TOP VIEW
BOTTOM VIEW
SIDE VIEW
0.08 C
RECOMMENDED LAND PATTERN
0.90 ±0.10
NOTES:
1.
JEDEC compatible.
2.
All dimensions are in mm and angles are in degrees.
3.
Use ±0.05 mm for the non-toleranced dimensions.
4.
Numbers in ( ) are for references only.
5.
Pin#1 ID is identified by either chamfer or notch.
C
(0.20)
0.05 Max
1
5
6
10
11
15
16
20
min 0.20
0.40 ±0.10
1.65 ±0.10
1.65 ±0.10
0.40
0.20
Package
Outline
1.65
3.30
2.20
1.65
1.65
0.20
0.40
A. PIN1 ID OPTION DETAILS
A. Pin1 ID
Option
A. Pin1 ID
Option
© Renesas Electronics Corporation
Package Outline Drawing
PSC-4179-02
NDG20P2
20-VFQFPN 3.0 x 3.0 x 0.9 mm Body, 0.4mm Pitch
Rev.03, May 5, 2025
