RC19302A00AGNT#BD0 datasheet(11/62 Pages) RENESAS

11 / 62 page

R31DS0210EU0106 Rev.1.06

Page 11

May 11, 2026

RC193xx Datasheet

2. Specifications

2.1

Absolute Maximum Ratings

Caution: Do not operate at or near the maximum ratings listed for extended periods of time. Exposure to such

conditions can adversely impact product reliability and result in failures not covered by warranty.

CLK2

O, DIF

True clock output.

CLKb2

O, DIF

Complementary clock output.

VDDCLK_0

PWR

Power supply for clock output bank 0.

VDDDIG

PWR

Digital power.

GNDSUB

GND

Ground pin for substrate.

EPAD

GND

Connect to ground.

Table 4. Absolute Maximum Ratings

Symbol

Parameter

Conditions

Minimum

Maximum

Unit

VDDx

Supply Voltage with respect to Ground

Any VDD pin

-0.5

2.2

VIN

Input Voltage for non-PDT inputs

Input pins not labeled as PDT

[1]

1. Inputs not designated Power Down Tolerant (PDT) in the pin description tables.

-0.5

VDDx + 0.3

VINPDT

Input Voltage for PDT inputs

PDT input pins, see below for

LOSb output pin [2]

2. Inputs designated Power Down Tolerant (PDT) in the pin description tables.

-0.5

3.6

VPUPSMB

Pull up resistor voltage for SMBus interface SCLK, SDATA pins

VPUPLOS

Pull up resistor voltage for LOSb pin

LOSb pin [3]

3. The VPUP voltage may be applied before main VDD is applied. The LOSb pin is PDT to this voltage, not to 3.6V.

-0.5

1.9

IIN

Input Current

All SE inputs and CLKIN [1]

+50

IOUT

Output Current – Continuous

CLK

SDATA

Output Current – Surge

CLK

SDATA

Maximum Junction Temperature

150

°C

Storage Temperature

-65

150

°C

ESD

Human Body Model

JESD22-A114 (JS-001)

Classification

2000

Charged Device Model

JESD22-C101 Classification

500

Table 3. RC19302A Pin Descriptions (Cont.)

Pin Number

Pin Name

Type

Description
