R31DS0210EU0106 Rev.1.06
Page 53
May 11, 2026
RC193xx Datasheet
A.2.2
28-VFQFPN
35
OEb2
Input
-
36
SADR_tri1
Input
-
37
CLK2
Output
-
38
CLKb2
Output
-
39
VDDCLK_0
Power
-
40
CLK1
Output
-
41
CLKb1
Output
-
42
SLEWRATE_SEL [1]
Input
-
43
OEb1
Input
-
44
OEb0
Input
-
45
CLK0
Output
-
46
CLKb0
Output
-
47
VDDCLK_0
Power
-
48
GNDSUB
Power
-
EPAD49
GND
Power
-
1. This pin is AMPLITUDE_SEL for the RC19308A001.
Pin Number
Primary Pin Name
Primary Electrical Type
Alternate Pin Name(s)
1
PWRGD_PWRDNb
Input
-
2
CLKIN0
Input
-
3
CLKINb0
Input
-
4
VDDIN0
Power
-
5
CLKIN1
Input
-
6
CLKINb1
Input
-
7
VDDIN1
Power
-
8
CLKSEL_tri
Input
-
9
OEb6
Input
-
10
CLK6
Output
-
11
CLKb6
Output
-
12
VDDCLK_1
Power
-
13
CLK5
Output
-
14
CLKb5
Output
-
15
SLEWRATE_SEL [1]
1. This pin is AMPLITUDE_SEL for the RC19304A001.
Input
-
16
OEb5
Input
-
17
LOSb
Output
-
18
VDDA
Power
-
19
OEb2
Input
-
20
CLK2
Output
-
21
CLKb2
Output
-
22
VDDCLK_0
Power
-
23
CLK1
Output
-
24
CLKb1
Output
-
25
OEb1
Input
-
26
VDDDIG
Power
-
27
GNDSUB
Power
-
28
ZOUTSEL_tri
Input
-
EPAD29
GND
Power
-
